HCPL2611S Real Image
Same model may have multiple batches, images only for reference.

HCPL2611S

Part No HCPL2611S
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description OPTOISO 2.5KV OPN COLLECTOR 8SMD / Optocoupler Logic-Out Open Collector DC-IN 1-CH 8-Pin PDIP SMD Black Tube
Datasheet
HCPL2611S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 2500Vrms
Common Mode Transient Immunity (Minimum) 10kV/μs
Input Type DC
Output Type Open Collector
Output Current per Channel 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Maximum) 75ns, 75ns
Rise / Fall Time (Typ) 50ns, 12ns
Voltage - Forward (Vf) (Typ) 1.4V
Current - DC Forward (If) (Maximum) 50mA
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 8-SMD, Gull Wing
Manufacturer Package 8-SMD
Win Source Part Number 775701-HCPL2611S
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1k pcs
Family Name HCPL2611
Introduction Date January 26, 2000
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL2611S CAD Model

Description

This 8-SMD, Gull Wing package isolator has an output current per channel of 50mA and a common mode transient immunity of 10kV/μs.

  • Output Current Per Channel: 50mA
  • Common Mode Transient Immunity: 10kV/μs
  • Operating Supply Voltage: 4.5 V ~ 5.5 V
  • Data Rate: 10Mbps
  • Supply and Demand Status: Limited

The manufacturer's homepage is not provided.
