Same model may have multiple batches, images only for reference.

FGH60N60SMD

Name: FGH60N60SMD
Brand: Fairchild/ON Semiconductor
SKU: 130478
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FGH60N60SMD
Manufacturer	Fairchild/ON Semiconductor
Catalog	IGBTs - Single
Description	IGBT 600V 120A 600W TO247
Datasheet	FGH60N60SMD Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Tube/Rail
Status	Active
IGBT Type	Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	120A
Pulsed Collector Current	180A
Collector-emitter saturation voltage(Max)	2.5V @ 15V, 60A
Maximum Power Dissipation	600W
Total Switching Energy(Ets)	1.26mJ (on), 450μJ (off)
Input Type	Standard
Gate Charge	189nC
Turn-on and Turn-off delay time	18ns/104ns
Testing Conditions	400V, 60A, 3 Ohm, 15V
Reverse Recovery Time (trr)	39ns
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	TO-247-3
Win Source Part Number	087618-FGH60N60SMD
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	FGH60N60SMD
Introduction Date	May 01, 2010
ECCN	EAR99
Country of Origin	China, Republic of Korea
Halogen Free	Compliant
Estimated EOL Date	2023
Quantity per package	450
Ultra Librarian 3D Model	Ultra Librarian FGH60N60SMD CAD Model

Description

The FGH60N60SMD is an IGBT type electronic component manufactured by Fairchild/ON Semiconductor. It has a balanced supply and demand status. The quantity per package is 450.

Maximum Collector-Emitter Breakdown Voltage: 600V
Maximum Collector Current: 120A
Gate Charge: 189nC
Collector-Emitter Saturation Voltage: 2.5V @ 15V, 60A
Operating Temperature: -55°C to 175°C
Package: TO-247-3
Maximum Power Dissipation: 600W
Reverse Recovery Time: 39ns
Total Switching Energy: 1.26mJ (on), 450μJ (off)
