FAN7388MX

Name: FAN7388MX
Brand: Fairchild/ON Semiconductor
SKU: 590741
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FAN7388MX
Manufacturer	Fairchild/ON Semiconductor
Catalog	PMIC - Gate Drivers
Description	3 Half-Bridge Gate-Drive IC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits (ICs)
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Driven Configuration	Half-Bridge
Channel Type	3-Phase
Number of Drivers	6
Gate Type	IGBT, N-Channel MOSFET
Operating Supply Voltage	10 V ~ 20 V
Logic Voltage - VIL, VIH	1V, 2.5V
Current - Peak Output (Source, Sink)	350mA, 650mA
High Side Voltage - Max (Bootstrap)	600V
Rise / Fall Time (Typ)	50ns, 30ns
Operating Temperature Range	-40°C ~ 150°C (TJ)
Mounting	SMD
Package	20-SOIC (0.295", 7.50mm Width)
Manufacturer Package	20-SOIC
Win Source Part Number	1173429-FAN7388MX
Manufacturer Homepage	www.fairchildsemi.com
Family Name	FAN7388
Introduction Date	May 20, 2008
ECCN	EAR99
Country of Origin	Taiwan
Halogen Free	Compliant
Estimated EOL Date	2025
Popularity	Medium
Supply and Demand Status	Sufficient
Quantity per package	1k pcs
Ultra Librarian 3D Model	Ultra Librarian FAN7388MX CAD Model

Description

The Fairchild/ON Semiconductor FAN7388MX is a 3-phase half-bridge gate driver that is designed to drive IGBTs and N-channel MOSFETs.

Number of Drivers: Six
Temperature Range: -40°C to 150°C (TJ)
Package: 20-SOIC (0.295", 7.50mm Width)
Operating Supply Voltage: 10 V to 20 V
High Side Voltage: 600V (max)
Peak Output Current (Source): 350mA
Peak Output Current (Sink): 650mA
Rise Time: 50ns (typ)
Fall Time: 30ns (typ)
