2N7002T

Part No 2N7002T
Manufacturer Fairchild/ON Semiconductor
Catalog FETs - Single
Description Trans MOSFET N-CH 60V 0.115A 3-Pin SOT-523FL T/R / MOSFET N-CH 60V 115MA SOT-523F
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Fairchild Semiconductor
Standard Package 1
Category Discrete Semiconductor Products
Family FETs - Single
Packaging Reel
FET Type MOSFET N-Channel Metal Oxide
FET Feature Standard
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25°C 115mA (Ta)
Rds On (Max) @ Id Vgs 7.5 Ohm @ 50mA 5V
Vgs(th) (Max) @ Id 2V @ 250µA
Input Capacitance (Ciss) @ Vds 50pF @ 25V
Power - Max 200mW
Operating Temperature Range 150°C (TJ)
Mounting Style SMD/SMT
Package SC-89 SOT-490
Manufacturer Device Package SOT-523F
Catalog N-Channel Logic Level Gate FETs
Win Source Part Number 075353-2N7002T
Popularity Medium
Supply and Demand Status Sufficient
Family Name 2N7002T
Introduction Date February 16, 2006
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian 2N7002T CAD Model

Description

2N7002T MOSFET Transistor

The 2N7002T is an advanced, small-signal N-channel MOSFET designed to deliver efficient switching and easy integration into various electronics applications.

  • Applications and Projects:
    • Telecommunications equipment
    • Industrial control systems
    • Automotive applications
    • Electronic test equipment
  • Features and Benefits:
    • Excellent thermal stability: Retains performance across a wide temperature range.
    • Minimal gate charge: Reduces losses and improves switching efficiency.
    • Space-saving package: Optimizes board layout.
    • High reliability: Suitable for use in critical applications.
  • Additional Details:
    • Operating temperature range: -55°C to +150°C
    • Drain-source voltage (VDS): 60V
    • Continuous drain current (ID): 260mA
