The 74VHCT04A is a hex inverter manufactured by Fairchild/Micross Components. It belongs to the VHCT (Very High-Speed CMOS, TTL-compatible) logic family, which combines the high speed of advanced CMOS with TTL-compatible input thresholds. This inverter is designed to invert six independent logic signals, making it a versatile component in digital circuits.

Applications

• Logic Signal Inversion
• Oscillators
• Pulse Shaping
• Line Driving
• Digital Signal Processing

Features

• Six independent inverters
• TTL-compatible input thresholds
• High-speed operation
• Low power consumption
• Wide operating voltage range
• Available in various packages (e.g., DIP, SOIC)

Benefits

• Provides reliable logic inversion for a variety of applications.
• Simplifies interfacing with TTL logic with its TTL-compatible input thresholds.
• Enables high-speed operation in digital circuits.
• Reduces power consumption in battery-powered devices.
• Offers design flexibility with its wide operating voltage range and various package options.

Additional Details

The 74VHCT04A operates over a voltage range of 4.5V to 5.5V. The propagation delay is fast which makes it suitable for high-speed applications. The TTL-compatible input thresholds allow the device to be directly interfaced with TTL logic levels. The device is typically used to invert logic signals, create oscillators, shape pulses, or drive lines. The low power consumption makes it suitable for battery-powered devices. The device is available in various packages, such as DIP and SOIC, to accommodate different mounting requirements. It is designed to meet industry standards for safety and performance. The device features a low quiescent current, further reducing power consumption. It is commonly used in applications requiring high speed, low power, and TTL compatibility, such as computer peripherals, communication equipment, and industrial controls.
