The XRT5676ID-F is a single-chip T1/E1/J1 framer designed by Exar Corporation, offering a highly integrated solution for telecommunications applications. Building upon the features of previous generations, it is designed for reliable data transmission over T1, E1, and J1 lines. It handles framing, clock recovery, and line interface functions, streamlining design and reducing component count in networking equipment.

Applications

• Channel Banks
• Digital Cross-Connect Systems (DCS)
• Private Branch Exchanges (PBX)
• Wireless Base Stations
• Voice over IP (VoIP) Gateways
• Test Equipment for T1/E1/J1 lines

Features

• Single-chip T1/E1/J1 framer
• Integrated clock recovery circuit
• Line build-out (LBO) support for varied cable lengths
• Jitter attenuation for signal integrity
• On-chip diagnostics with loopback capabilities
• Microprocessor interface for configuration and control
• Low power consumption enhancing energy efficiency
• Compliance with T1 (DS1), E1, and J1 standards ensuring interoperability
• Supports short-haul and long-haul applications

Benefits

• Reduced system cost from high integration
• Improved system performance through reliable clock recovery and jitter attenuation
• Simplified design expedites time-to-market
• Enhanced system reliability via on-chip diagnostics
• Lower power consumption contributes to energy-efficient designs
• Flexible configuration through the microprocessor interface
• Guaranteed compliance with industry standards ensuring seamless interoperability

Additional Details

The XRT5676ID-F typically operates from a single 3.3V power supply. Diagnostic capabilities such as loopback modes enable thorough testing of the line interface and internal circuitry. The microprocessor interface offers extensive configuration options, including line build-out, clock source, and framing mode. The device is available in a compact package suitable for space-constrained designs. Utilizing a phase-locked loop (PLL), the clock recovery circuit effectively extracts the clock signal from the incoming data stream, maintaining data accuracy even with jitter. It supports various line coding formats, including AMI, B8ZS, and HDB3. Integrated line build-out circuitry compensates for signal loss from cable attenuation, ensuring robust data transmission across varying distances. Comprehensive status and alarm monitoring facilitate rapid fault detection and isolation. The 'F' suffix likely indicates lead-free construction, aligning with environmental regulations.
