XRP6272IDBTR-F Exar Corporation XRP6272IDBTR-F label picture XRP6272IDBTR-F real image
Same model may have multiple batches, images only for reference.
XRP6272IDBTR-F Exar Corporation XRP6272IDBTR-F label picture XRP6272IDBTR-F real image
XRP6272IDBTR-F Exar Corporation XRP6272IDBTR-F label picture XRP6272IDBTR-F real image
Same model may have multiple batches, images only for reference.

XRP6272IDBTR-F

Part No XRP6272IDBTR-F
Manufacturer Exar Corporation
Catalog PMIC - Voltage Regulators - Linear
Description 2A 5V-Adjustable Low Dropout Voltage Regulator | IC REG LINEAR POS ADJ 2A 8HSOICN
Datasheet
XRP6272IDBTR-F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer MaxLinear, Inc.
Packaging Reel
Output Type Adjustable (Fixed)
Voltage - Input (Maximum) 6V
Min/Fixed Output Voltage 0.7V (5V)
Maximum Output Voltage 5.4V
Maximum Dropout Voltage 0.6V at 2A
Output Current 2A
Current - Quiescent (Iq) 50μA
PSRR 70dB (1kHz)
Control Features Enable, Power Good
Protection Features Over Current, Over Temperature, Soft Start
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-SOIC Exposed Pad
Supplier Device Package 8-HSOICN
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1282342-XRP6272IDBTR-F
Manufacturer Homepage www.exar.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, RF Communications, Portable Devices
Family Name XRP6272
Introduction Date October 14, 2011
ECCN EAR99
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian XRP6272IDBTR-F CAD Model

Description

The MaxLinear, Inc. XRP6272IDBTR-F is an adjustable (fixed) output type integrated circuit (IC) that comes in an 8-HSOICN package.

  • Package: 8-HSOICN
  • Output Current: 2A
  • Maximum Output Voltage: 5.4V
  • PSRR: 70dB @ 1kHz
  • Protection Features: over current, over temperature, and soft start
  • Operating Temperature Range: -40°C to 85°C
  • Voltage Input Range (Maximum): 6V
  • Minimum/Fixed Output Voltage: 0.7V (5V)
