B82724J2602N001

Part No B82724J2602N001
Manufacturer EPCOS (TDK)
Catalog Common Mode Chokes
Description CMC 1MH 6A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 1 mH @ 100 kHz
Current Rating (Max) 6A
DC Resistance (DCR) (Max) 23mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Approval Agency ENEC, UR, VDE
Mounting Type Through Hole
Size / Dimension 1.232" L x 0.728" W (31.30mm x 18.50mm)
Height (Max) 1.307" (33.20mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1530398-B82724J2602N001
Ultra Librarian 3D Model Ultra Librarian B82724J2602N001 CAD Model
