Products specifications

Category Fans, Thermal Management - Fans - AC Fans
Mfr ebm-papst
Series 9900
Package Bulk
Product Status Active
Voltage - Rated 230VAC
Size / Dimension Square - 119mm L x 119mm H
Width 25.40mm
Air Flow 68.9 CFM (1.93m³/min)
Bearing Type Sintec
Fan Type Tubeaxial
Noise 37.0dB(A)
Power (Watts) 14.00W
RPM 2450 RPM
Termination 2 Terminals
Temperature Range - Operating -4 ~ 158°F (-20 ~ 70°C)
Approval Agency CE, CSA, UL, VDE
Material - Frame Aluminum
Material - Blade Polyamide (PA), Nylon
Lifetime @ Temp. 47500 Hrs @ 40°C
Standard Package 1 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8414.59.6590
Win Source Part Number 551616-9950
Ultra Librarian 3D Model Ultra Librarian 9950 CAD Model

Description

The 535869 is an AC fan designed for thermal management applications. Manufactured by ebm-papst, this fan belongs to the 9900 series and has a square shape with dimensions of 119mm x 119mm.

  • Series: 9900
  • Shape: Square
  • Dimensions: 119mm x 119mm
  • Rated Voltage: 230VAC
  • Power Consumption: 14.00W
  • Speed: 2450 RPM
  • Air Flow: 68.9 CFM
  • Bearing Type: Sintec
  • Materials: Aluminum
  • Temperature Range: -20°C to 70°C
  • Approvals: CE, CSA, UL, and VDE
