Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Switches>Slide Switches
Mfr E-Switch
Series EG
Package Bulk
Circuit DPDT
Contact Timing Non-Shorting (BBM)
Switch Function On-On
Current Rating (Amps) 200mA (DC)
Voltage Rating - DC 30 V
Actuator Type Standard
Actuator Length 6.00mm
Contact Material Copper Alloy
Contact Finish Silver
Mounting Type Through Hole
Termination Style PC Pin
Temperature Range - Operating -20°C ~ 70°C
Switch Travel 4.00mm
Operating Force 200gf
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9050
Other Names P040071,EG1905,Q6651229
Standard Package 300
Win Source Part Number 1182584-EG2201A
Ultra Librarian 3D Model Ultra Librarian EG2201A CAD Model

Description

The EG2201A is a DPDT slide switch manufactured by E-Switch.

  • Switch Type: DPDT Slide
  • Mounting: Through-Hole
  • Voltage Rating: 30 VDC
  • Supply and Demand: Balanced
  • Contact Timing: Non-Shorting (BBM)
  • Operating Force: 200gf
