SMCJ28CA-13-F TVS Diode by Diodes Incorporated

The SMCJ28CA-13-F from Diodes Incorporated is a robust transient voltage suppressor (TVS) diode designed to protect sensitive electronic equipment from voltage transients induced by system inductance, lightning, and other transient voltage events. This TVS diode is a bidirectional device, meaning it can provide protection in both forward and reverse directions, making it an ideal choice for AC applications or where the polarity is reversible.

Key Features

• Stand-Off Voltage: The device has a stand-off voltage of 28V, which is the maximum voltage that can be applied while maintaining a high resistance state.
• Peak Pulse Power: It can handle a peak pulse power of 1500 Watts at 10/1000μs waveform, ensuring effective protection against high energy transients.
• Clamping Voltage: With a clamping voltage of 45.4V, this TVS diode provides a rapid response to the transient over-voltages, safeguarding the downstream components from damage.
• Low Leakage Current: The low leakage current of the device ensures minimal power loss when the diode is in the standby state, enhancing the overall efficiency of the application it is used in.
• Package: Encased in a DO-214AB (SMC) package, SMCJ28CA-13-F is designed to be both durable and space-efficient, suitable for high-density circuit board designs.
• Compliance: This component meets the MSL level 1 standard, per J-STD-020, and is compliant with both RoHS and REACH regulations, reflecting Diodes Incorporated's commitment to environmental responsibility.

Applications

The versatility of the SMCJ28CA-13-F makes it suitable for a wide array of applications, including:

• Power supply circuits
• Automotive systems
• Communication devices
• Industrial electronics
• Consumer electronics

With its high surge capability and fast response time, the SMCJ28CA-13-F TVS diode from Diodes Incorporated provides critical protection for electronic circuits, ensuring reliability and longevity of the products it is used in.
