Products specifications

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Diodes Incorporated
Package Tube
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Max) @ If 790 mV @ 20 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 100 µA @ 100 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220-3
Base Product Number SDT40100
Other Names SDT40100CTDI,SDT40100CT
Standard Package 50
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1283066-SDT40100CT
Ultra Librarian 3D Model Ultra Librarian SDT40100CT CAD Model

Description

The SDT40100CT from Diodes Incorporated is a high-performance, dual trench Schottky rectifier designed for applications requiring low voltage drop and high efficiency. This component is ideal for use in power supply units, converters, free-wheeling diodes, reverse battery protection, and other power management tasks.

Key Features

  • High Current Capability: The SDT40100CT can handle up to 40A of average rectified current (I<sub>AV), with 20A per diode, making it suitable for high-current applications.
  • Low Forward Voltage Drop: The device features a low forward voltage drop (V<sub>F), which enhances power efficiency and reduces thermal stress on the system.
  • High Surge Capability: With its high surge current capability, this rectifier can withstand transient overloads, ensuring reliability and robustness in challenging conditions.
  • Power Dissipation: The device boasts a power dissipation of 150W, allowing it to handle significant energy without overheating.
  • Dual Diode Configuration: The two diodes are configured in a common cathode arrangement, making it convenient for use in full-bridge and half-bridge circuits.
  • TO-220AB Package: The SDT40100CT is encapsulated in a TO-220AB package, known for its thermal efficiency and ease of mounting on a PCB or heatsink.

Applications

The SDT40100CT is versatile and can be used in a wide range of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Automotive environments
  • Power inverters
  • Or-ing diode in redundant power systems

Technical Specifications

Parameter Value Average Rectified Current (I<sub>AV) 40A Forward Voltage Drop (V<sub>F) Typically 0.85V at 20A Surge Current Capability High Power Dissipation 150W Package TO-220AB

For detailed information, datasheets, and technical support, customers are advised to visit Diodes Incorporated's official website or contact their local sales representative.
