Introducing the SBR660CTL-13 from Diodes Incorporated

The SBR660CTL-13 is a cutting-edge product from Diodes Incorporated, a leading manufacturer in the semiconductor industry. This device is part of their Super Barrier Rectifier (SBR®) series, which is designed to offer superior performance in power rectification applications. The SBR660CTL-13 is particularly suited for high-frequency environments and is commonly used in power supplies, lighting, and other electronic applications that require high efficiency and reliability.

Key Features

• Low Forward Voltage Drop (VF): The device boasts a low VF, which enhances its efficiency by minimizing power loss during operation.
• High Surge Capability: With its robust surge handling capacity, the SBR660CTL-13 can withstand transient over-voltage conditions, ensuring the protection of the circuit components it is connected to.
• Power Pak® Package: Encased in a Power Pak® package, the SBR660CTL-13 ensures a compact footprint while providing excellent thermal performance and power handling capabilities.
• RoHS Compliant: In line with modern environmental standards, this product is RoHS compliant, meaning it is manufactured without the use of hazardous substances.

Applications

The SBR660CTL-13 is versatile and can be integrated into a variety of applications. It is particularly effective in:

• Switch Mode Power Supplies (SMPS)
• LED Lighting
• Free-Wheeling Diodes
• Reverse Battery Protection
• Automotive Applications

Technical Specifications

The SBR660CTL-13 is a dual diode device with a 60A average rectified current rating and a 100V reverse voltage rating. It is designed to operate efficiently even at high temperatures, with a junction temperature range of -55°C to 150°C. Its high-reliability factor is further bolstered by its compliance with the AEC-Q101 standard, making it suitable for automotive applications.

With its combination of efficiency, durability, and versatility, the SBR660CTL-13 from Diodes Incorporated is an excellent choice for designers looking to enhance the performance and reliability of their power management systems.
