The SBR20A200CTB is a high-performance, dual common-cathode Super Barrier Rectifier (SBR) designed by Diodes Incorporated, a leading manufacturer and supplier of high-quality semiconductor products. This rectifier is engineered to provide superior switching performance and high thermal stability. It is ideal for a wide range of applications, including power management, automotive systems, and high-frequency circuits.

Key Features

• High Surge Capability: The SBR20A200CTB is capable of withstanding high surge currents, making it suitable for applications that experience transient overvoltage conditions.
• Low Forward Voltage Drop: This device offers a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
• High-Temperature Operation: With an operating junction temperature range of -55°C to +150°C, the SBR20A200CTB is designed to perform reliably in extreme temperature environments.
• Low Leakage Current: The low reverse leakage current characteristic of this rectifier helps to reduce power consumption, especially in idle or standby modes.
• TO-263 Package: The SBR20A200CTB comes in a TO-263 (D2PAK) package, which is known for its excellent power dissipation and small footprint on PCBs.

Applications

• Power Supply Units (PSUs)
• Automotive Charging Systems
• DC-DC Converters
• Free-Wheeling Diodes in Inverters
• Lighting Circuits

Electrical Characteristics

The SBR20A200CTB boasts a continuous forward current of 20A and a repetitive peak reverse voltage of 200V. Its maximum forward voltage is specified at 0.95V, and the maximum reverse leakage current is rated at 500µA, both at 125°C. These specifications ensure that the SBR20A200CTB can handle high-power and high-voltage requirements with ease.

Quality and Reliability

Diodes Incorporated is committed to providing products that meet the highest standards of quality and reliability. The SBR20A200CTB is no exception, having undergone rigorous testing to ensure its performance under various conditions. It is also RoHS compliant, reflecting the company's dedication to environmental responsibility.
