The PI7C9X130DNDE is a state-of-the-art PCIe-to-PCI bridge designed by Diodes Incorporated to facilitate seamless communication between a PCI Express (PCIe) bus and a legacy PCI bus. This innovative product is ideal for extending the life of PCI-based devices and ensuring their compatibility with newer PCIe-based systems.

Key Features

• PCI Express Base Specification Compliance: The device adheres to the PCIe 1.1 specification, ensuring reliable and high-speed connectivity.
• PCI Specification Support: It is compatible with the PCI Local Bus Specification Revision 2.3, offering broad support for legacy PCI devices.
• High Performance: With a 32-bit, 33/66MHz PCI interface, the bridge can facilitate efficient data transfer between the two bus standards.
• Flexible Bus Operation: The PI7C9X130DNDE supports both primary and secondary bus mastering, providing versatility in system design and resource management.
• Enhanced Data Integrity: The inclusion of parity error detection on the PCI interface ensures data integrity during transactions.

Applications

The bridge is suited for a variety of applications that require the integration of PCI devices into PCIe systems. It is commonly used in:

• Industrial Computers
• Embedded Systems
• Server and Workstation Bridges
• Data Acquisition Systems
• Test Equipment

Technical Specifications

For developers and system integrators looking to incorporate legacy PCI devices within modern PCIe infrastructures, the PI7C9X130DNDE from Diodes Incorporated offers a reliable and efficient solution. Its compliance with both PCIe and PCI specifications ensures compatibility and a straightforward integration process.
