Introducing the AL8860MP-13 Buck LED Driver

The AL8860MP-13 from Diodes Incorporated is a highly efficient, step-down DC/DC converter specifically designed to drive single or multiple series connected LEDs at a constant current. This innovative component offers a perfect solution for LED lighting applications, where high efficiency, compact design, and reliability are paramount.

Key Features of the AL8860MP-13

• Wide Input Voltage Range: The device operates from an input voltage range of 5V to 36V, making it versatile for use in various applications, from industrial lighting to automotive systems.
• High Efficiency: With up to 96% efficiency, this LED driver ensures minimal power loss and is suitable for battery-powered applications where energy conservation is critical.
• Constant Current Output: The AL8860MP-13 provides a constant current output, which can be set via an external resistor. This feature ensures uniform brightness and prolongs the life of the LEDs.
• Thermal Protection: The device includes thermal shutdown protection to safeguard the LED driver from overheating, thereby enhancing its durability and reliability.
• Adjustable Output Current: Users can adjust the output current from 0.3A to 1A, allowing for flexibility in controlling the brightness of the connected LEDs.
• Compact Package: Offered in a small footprint MSOP-8EP package, the AL8860MP-13 is ideal for space-constrained applications.

Applications

The AL8860MP-13 is well-suited for a variety of lighting applications, including:

• Architectural and decorative lighting
• Commercial and residential LED lighting
• Automotive interior or exterior lighting
• Industrial illumination
• LED backlighting systems

With its robust design, the AL8860MP-13 ensures a long operational life for LED arrays, providing a cost-effective and energy-efficient solution for high-performance lighting systems. Its ease of integration and user-friendly features make it an excellent choice for designers and engineers looking to enhance their lighting applications.
