Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Development Boards, Kits, Programmers - Evaluation Boards - Expansion Boards, Daughter Cards
Mfr DFRobot
Package Bulk
Product Status Obsolete
Platform Intel® Edison
Type Interface
Function I/O Expansion
Utilized IC / Part AAT4610A, FT232R, MP2307, PAM2305, TXB0108
Contents Board(s)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 768442-DFR0338
Ultra Librarian 3D Model Ultra Librarian DFR0338 CAD Model

Description

The 768442-DFR0338 is an evaluation board designed for I/O expansion.

  • Platform: Intel® Edison
  • ICs and Parts: AAT4610A, FT232R, MP2307, PAM2305, TXB0108
  • Package Type: Bulk
  • Standard Package: 1 piece
  • ECCN: EAR99
  • HTSUS Code: 8473.30.1180
  • Status: Obsolete
