LNE-36V320WAAA Delta Electronics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

LNE-36V320WAAA

Part No LNE-36V320WAAA
Manufacturer Delta Electronics
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRVR CC/CV AC/DC 36V 8.9A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Programmable Not Verified
Type Constant Current, Voltage
Topology AC DC Converter
Number of Outputs 1
Voltage - Input (Min) 90VAC
Voltage - Input (Max) 305VAC
Voltage - Output 18 ~ 36V
Current - Output (Max) 8.9A
Power (Watts) 320 W
Voltage - Isolation 3.85 kV
Dimming Analog, PWM
Features OCP, OTP, OVP, SCP
Ratings IP65
Temperature Range - Operating -40°C ~ 70°C
Efficiency 94.5%
Termination Style Wire Leads
Size / Dimension 9.92" L x 3.54" W x 1.72" H (252.0mm x 89.9mm x 43.7mm)
Approval Agency UL
Standard Number 50581; 55015; 55024; 61000-3-2; 61000-3-3; 61347-1; 61347-2-13; 62384
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1572059-LNE-36V320WAAA
Ultra Librarian 3D Model Ultra Librarian LNE-36V320WAAA CAD Model
