The TBF-2012-245-RH is a common mode choke manufactured by Cyntec. Common mode chokes are designed to suppress common-mode noise in electronic circuits. Common-mode noise is a type of electromagnetic interference (EMI) that appears simultaneously on multiple conductors relative to a common reference point (usually ground). This choke effectively reduces this noise, improving signal integrity and overall system performance.

Applications

• Suppression of common-mode noise in USB interfaces
• Filtering common-mode noise in Ethernet connections
• Noise reduction in power lines
• Filtering in signal lines to reduce EMI
• Differential signal noise reduction

Features

• High Common Mode Impedance: Offers high impedance to common-mode noise, effectively attenuating unwanted signals.
• Low Differential Mode Impedance: Exhibits low impedance to differential-mode signals, allowing desired signals to pass through with minimal attenuation.
• Compact Size: Small form factor suitable for space-constrained applications.
• RoHS Compliant: Compliant with RoHS directives, ensuring environmental friendliness.
• High Reliability: Designed for reliable performance in demanding environments.

Benefits

• Improved Signal Integrity: Reduces common-mode noise, leading to cleaner signals and improved data transmission.
• Reduced EMI: Minimizes electromagnetic interference, preventing unwanted radiation and improving system compatibility.
• Enhanced System Performance: Cleaner signals and reduced EMI contribute to overall improved system performance and reliability.
• Easy Integration: Compact size and standard footprint simplify integration into existing circuit designs.
• Environmental Compliance: RoHS compliance ensures that the product meets environmental regulations.

Technical Specifications

The TBF-2012-245-RH common mode choke from Cyntec will have specific values for impedance at certain frequencies, DC resistance (DCR), rated current, and insulation resistance, and these details can be found on the manufacturer's datasheet.
