Same model may have multiple batches, images only for reference.

PEME2-S24-D15-S

Name: PEME2-S24-D15-S
Brand: CUI Inc.
SKU: 1078473
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PEME2-S24-D15-S
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC-DC 3KV ISOLATED, 2 W, 21.6~26 / Isolated Module DC DC Converter 2 Output 15V -15V 67mA, 67mA 21.6V - 26.4V Input
Datasheet	PEME2-S24-D15-S Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	CUI Inc.
Series	PEME2-S (2W)
Package	Tube
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	21.6V
Voltage - Input (Max)	26.4V
Voltage - Output 1	15V
Voltage - Output 2	-15V
Current - Output (Max)	67mA, 67mA
Power (Watts)	2.01 W
Voltage - Isolation	3 kV
Applications	ITE (Commercial)
Features	Adjustable Output
Temperature Range - Operating	-40°C ~ 105°C (With Derating)
Efficiency	83%
Mounting Type	Through Hole
Package / Case	7-SIP Module, 5 Leads
Dimension	0.77" L x 0.28" W x 0.40" H (19.7mm x 7.1mm x 10.2mm)
Approval Agency	CE, cURus
Standard Number	62368-1
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	102-PEME2-S24-D15-S
Standard Package	25
Win Source Part Number	1078473-PEME2-S24-D15-S
Ultra Librarian 3D Model	Ultra Librarian PEME2-S24-D15-S CAD Model

Alternative Products

Description

The PEME2-S24-D15-S is a 2W isolated DC-DC converter with an adjustable output feature.

Power: 2W
Isolation: Isolated
Output: Adjustable
Input Voltage: 21.6V to 26.4V
Output Voltage: ±15V
Application: ITE (Commercial)
Package: 7-SIP module, 5 leads
Output Current: 67mA (max)
Operating Temperature: -40°C to 105°C
