Same model may have multiple batches, images only for reference.
MGFS154812 Real Image
Same model may have multiple batches, images only for reference.

MGFS154812

Part No MGFS154812
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V
Datasheet
MGFS154812 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Cosel USA, Inc.
Series MGFS
Type Isolated Module
Number of Outputs 1
Input Voltage MIN 18V
Voltage Input MAX 76V
Voltage - Output 1 12V
Current - Output (Maximum) 1.3A
Voltage - Isolation 1.5kV (1500V)
Applications ITE (Commercial)
Features Remote On/Off, OCP
Operating Temperature Range -40°C ~ 85°C (With Derating)
Efficiency 88%
Mounting Style Through Hole
Package 6-DIP Module
Size 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
Win Source Part Number 759813-MGFS154812
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name MGFS15
Introduction Date October 18, 2010
Country of Origin Japan
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MGFS154812 CAD Model

Description

The MGFS series isolated module power supply from Cosel USA, Inc. is a board mount DC-DC converter that features remote on/off and OCP.

  • Package: 6-DIP module
  • Applications: ITE (Commercial)
  • Voltage Isolation: 1.5kV (1500V)
  • Output: 1
  • Output Voltage: 12V
  • Maximum Output Current: 1.3A
  • Input Voltage: 18V to 76V
  • Efficiency: 88%
  • Mounting: Through-hole
  • Package/Case: 6-DIP module (1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm))
