Same model may have multiple batches, images only for reference.

SK220M160ST

Get a Quote

Part No	SK220M160ST
Manufacturer	Cornell Dubilier Electronics (CDE)
Catalog	Aluminum Capacitors
Datasheet	SK220M160ST Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Cornell Dubilier Electronics (CDE)
Series	SK
Package	Bulk
Capacitance	22 µF
Tolerance	±20%
Voltage - Rated	160 V
ESR (Equivalent Series Resistance)	9.05Ohm @ 120Hz
Lifetime @ Temp.	2000 Hrs @ 85°C
Temperature Range - Operating	-25°C ~ 85°C
Polarization	Polar
Applications	General Purpose
Ripple Current @ Low Frequency	110 mA @ 120 Hz
Ripple Current @ High Frequency	154 mA @ 1 kHz
Lead Spacing	0.197" (5.00mm)
Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.787" (20.00mm)
Mounting Type	Through Hole
Package / Case	Radial, Can
Standard Package	200
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0020
Win Source Part Number	1308203-SK220M160ST
Ultra Librarian 3D Model	Ultra Librarian SK220M160ST CAD Model

Description

The Cornell Dubilier Electronics (CDE) SK series aluminum electrolytic capacitor is designed for general-purpose applications.

Capacitance: 22 µF
Tolerance: ±20%
Rated Voltage: 160 V
ESR (Equivalent Series Resistance): 9.05Ohm @ 120Hz
Ripple Current @ low frequency: 110 mA @ 120 Hz
Ripple Current @ high frequency: 154 mA @ 1 kHz
Lifetime: 2000 Hrs @ 85°C
Package: Radial, can
Lead Spacing: 0.197" (5.00mm)
Mounting Type: Through-hole
Dimensions: 0.394" Dia (10.00mm)
Temperature Range: -25°C ~ 85°C
