CM315D32768DZFT Real Image CM315D32768DZFT real image21548 CM315D32768DZFT real image21549
Same model may have multiple batches, images only for reference.
CM315D32768DZFT Real Image CM315D32768DZFT real image21548 CM315D32768DZFT real image21549
CM315D32768DZFT Real Image CM315D32768DZFT real image21548 CM315D32768DZFT real image21549
Same model may have multiple batches, images only for reference.

CM315D32768DZFT

Part No CM315D32768DZFT
Manufacturer Citizen Finedevice Co Ltd
Catalog Crystals
Description CRYSTAL 32.7680KHZ 12.5PF SMD / Crystal 0.032768MHz ±20ppm (Tol) 9pF Flexural 70000Ohm 2-Pin CSMD
Datasheet
CM315D32768DZFT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Crystals, Oscillators, Resonators
Manufacturer Citizen Finedevice Co Ltd
Series CM315D
Packaging Reel package
Type kHz Crystal (Tuning Fork)
Frequency 32.768kHz
Frequency Tolerance ±20ppm
Load Capacitance 12.5pF
ESR (Equivalent Series Resistance) 70 kOhm
Operating Mode Fundamental
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 2-SMD, No Lead
Dimension 0.126" L x 0.059" W (3.20mm x 1.50mm)
Height - Seated (Maximum) 0.035" (0.90mm)
Win Source Part Number 771619-CM315D32768DZFT
Popularity Medium
Supply and Demand Status Limited
Introduction Date September 24, 2012
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian CM315D32768DZFT CAD Model

Description

The CM315D32768DZFT crystal oscillator is a high-quality product manufactured by Citizen Finedevice Co Ltd.

  • Frequency: 32.768kHz
  • Load Capacitance: 12.5pF
  • Mode: Fundamental
  • Frequency Tolerance: ±20ppm
  • Operating Temperature: -40°C to 85°C
  • Package: 2-SMD, no lead
  • Mounting: SMD
  • Popularity: Medium
  • Supply: Limited
  • REACH: Yes
  • Halogen-Free: Yes
