Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Bulk
Status Obsolete
Transistor Type PNP
Current - Collector (Ic) (Maximum) 10A
Voltage - Collector Emitter Breakdown (Maximum) 100V
DC Current Gain (hFE) (Minimum) at Ic, Vce 100 at 3A, 4V
Maximum Power 80W
Frequency - Transition 3MHz
Temperature Range - Operating -65°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package TO-218-3
Supplier Device Package TO-218
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1267443-TIP34C
Manufacturer Homepage www.mospec.com.tw
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TIP34C CAD Model

Description

The TIP34C is a Central Semiconductor Corp manufactured electronic component.

  • Transistor Type: PNP
  • Frequency Transition: 3MHz
  • Design: designed for use in discrete semiconductor products.
  • Status: obsolete
  • Popularity: medium
  • Supply and Demand Status: balanced
  • Manufacturer's Homepage: www.mospec.com.tw
  • Win Source Part Number: 1267443-TIP34C
  • Supplier Device Package: TO-218
  • Manufacturer Package: TO-218-3
  • Current Collector (Ic) Maximum: 10A
  • Voltage Collector Emitter Breakdown (Maximum): 100V
  • Alternative Parts: 2SA1908, 2SB816-E, and 2SA1804R.
