Part No UPG2176T5N
Manufacturer CEL
Catalog RF Switches
Description IC SW SPDT 2.3-5.85GHZ 6-TSON
Datasheet
UPG2176T5N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Packaging Reel
Part Status Obsolete
Frequency - Lower 2.3GHz
Frequency - Upper 5.85GHz
Isolation @ Frequency 21dB @ 5.85GHz (typ)
Insertion Loss @ Frequency 0.7dB @ 5.85GHz
Topology Absorptive
Circuit SPDT
P1dB 37dBm (typ) IP1dB
Impedance 50 Ohm
Temperature Range - Operating -45°C ~ 85°C
RF Type 802.11a/b/g/n
Case 6-XFDFN Exposed Pad
Supplier Device Package 6-TSON
Win Source Part Number UPG2176T5N-E2-A-396021
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UPG2176T5N CAD Model

Description

The CEL UPG2176T5N-E2-A-396021 is a SPDT absorptive circuit with a frequency range of 2.3GHz to 5.85GHz.

  • Impedance: 50 Ohm
  • Isolation: 21dB @ 5.85GHz (typ)
  • Insertion Loss: 0.7dB @ 5.85GHz
  • P1dB: 37dBm (typ) IP1dB
  • RF Type: 802.11a/b/g/n
  • Package: The device comes in a 6-TSON supplier device package with a temperature range of -45°C to 85°C.
