UPD5713TK-E2-A Real Image UPD5713TK-E2-A real image UPD5713TK-E2-A label picture
Same model may have multiple batches, images only for reference.
UPD5713TK-E2-A Real Image UPD5713TK-E2-A real image UPD5713TK-E2-A label picture
UPD5713TK-E2-A Real Image UPD5713TK-E2-A real image UPD5713TK-E2-A label picture
Same model may have multiple batches, images only for reference.

UPD5713TK-E2-A

Part No UPD5713TK-E2-A
Manufacturer CEL
Catalog RF Switches
Description RF Switch SPDT 50MHz to 2.5GHz 20dB 6-Pin LeadLess Mini-Mold T/R / IC SWITCH SPDT 6-MINIMOLD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Packaging Reel - TR
Status Obsolete(EOL)
Frequency - Lower 50MHz
Frequency - Upper 2.5GHz
Isolation @ Frequency 22.5dB @ 2.5GHz (typ)
Insertion Loss @ Frequency 0.95dB @ 2.5GHz
Topology Reflective
Circuit SPDT
P1dB 21dBm (typ) IP1dB
Impedance 50 Ohm
Temperature Range - Operating -45°C to 85°C
Supply Voltage - Operating 1.8 V to 3.6 V
RF Type 802.15.1/Bluetooth, Cellular, PCS, WLAN, WLL
Case / Package 6-Minimold
Win Source Part Number 036116-UPD5713TK-E2-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name uPD5713
Introduction Date February 21, 2006
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian UPD5713TK-E2-A CAD Model

Description

The CEL uPD5713TK-E2-A is an electronic component that is commonly used in various electronic devices.

  • Status: Obsolete
  • Supply and Demand: Limited
  • Win Source part number: 036116-UPD5713TK-E2-A
  • Circuit: Reflective SPDT circuit
  • Frequency Range: 50MHz to 2.5GHz
  • Isolation: 22.5dB @ 2.5GHz
  • Insertion Loss: 0.95dB @ 2.5GHz
  • Supply Voltage Range: 1.8V to 3.6V
  • Applications: RF/IF and RFID applications
