Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer CEL
Packaging Tray
Status Active
Purpose Deserializer
Data Rate 784Mbps
Input Type LVDS
Output Type CMOS/TTL
Number of Inputs 5
Number of Outputs 35
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -20°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 64-TQFP (10x10)
Win Source Part Number 126582-THC63LVD104C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name THC63LVD104C
Introduction Date December 05, 2010
Country of Origin China, Japan, Taiwan
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian THC63LVD104C CAD Model

Description

The THC63LVD104C from CEL is a deserializer integrated circuit (IC) that can convert five LVDS input signals into 35 CMOS/TTL output signals.

  • Data Rate: 784Mbps
  • Applications: LCD monitors, projectors, and automotive displays
  • Package: 64-TQFP (10x10)
  • Supply Voltage Range: 3V to 3.6V
  • Temperature Range: -20°C to 85°C (TA)
  • Estimated EOL Date: 2023
  • Market Status: Common-used part with high popularity, and the supply and demand status is balanced
