PS8101-F3-AX

Name: PS8101-F3-AX
Brand: CEL
SKU: 281382
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PS8101-F3-AX
Manufacturer	CEL
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 3.75KV TRANS 6SO / DC-IN 1-CH Transistor With Base DC-OUT 5-Pin SOP T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	CEL
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	15% @ 16mA
Maximum DC Current Transfer Ratio	35% @ 16mA
Switching Turn-On and Turn-Off Time	500ns, 600ns
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	35V
Channel Output Current	8mA
Forward Voltage	1.7V
Continuous forward current- Max	25mA
Temperature Range - Operating	-55°C to 100°C
Mounting	SMD (SMT)
Case / Package	5-SOP
Win Source Part Number	026905-PS8101-F3-AX
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	PS8101
Introduction Date	June 07, 2005
ECCN	EAR99
Estimated EOL Date	Not Applicable
Ultra Librarian 3D Model	Ultra Librarian PS8101-F3-AX CAD Model

Description

The CEL PS8101-F3-AX transistor output optocoupler is a single-channel device that is used in isolator applications.

Isolation Voltage: 3750Vrms
Maximum Output Voltage: 35V
Mounting: surface-mount device (SMD)
Case: 5-SOP
Minimum DC Current Transfer Ratio: 15% @ 16mA
Maximum DC Current Transfer Ratio: 35% @ 16mA
Switching Turn-On Time: 500ns
Switching Turn-Off Time: 600ns
