PS2805C-4-F3-A CEL PS2805C-4-F3-A real image4959
Same model may have multiple batches, images only for reference.
PS2805C-4-F3-A CEL PS2805C-4-F3-A real image4959
PS2805C-4-F3-A CEL PS2805C-4-F3-A real image4959
Same model may have multiple batches, images only for reference.

PS2805C-4-F3-A

Part No PS2805C-4-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description AC-IN 4-CH Transistor DC-OUT 16-Pin SSOP T/R / OPTOISO 2.5KV 4CH TRANS 16SOIC
Datasheet
PS2805C-4-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 10μs, 7μs
Rise and Fall Time 5μs, 7μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 30mA
Forward Voltage 1.2V
Continuous forward current- Max 30mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 026892-PS2805C-4-F3-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name PS2805C-4
Introduction Date August 13, 2007
ECCN EAR99
Country of Origin Japan, Taiwan
Ultra Librarian 3D Model Ultra Librarian PS2805C-4-F3-A CAD Model

Description

The CEL PS2805C-4-F3-A is a high popularity component with a balance supply and demand status.

  • Product Name: CEL PS2805C-4-F3-A
  • Popularity: High
  • Supply and Demand Status: Balance
  • Type: Isolator
  • Channels: 4
  • Isolation Voltage: 2500Vrms
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Maximum DC Current Transfer Ratio: 400% @ 5mA
  • Application: Suitable for use in electronic circuits that require a high popularity component with a balance supply and demand status.
  • Packaging: 16-SSOP
  • Switching Turn-On Time: 10μs
  • Switching Turn-Off Time: 7μs
