MGA-87563-TR1G Real Image MGA-87563-TR1G Real Image1 MGA-87563-TR1G Real Image2
Same model may have multiple batches, images only for reference.
MGA-87563-TR1G Real Image MGA-87563-TR1G Real Image1 MGA-87563-TR1G Real Image2
MGA-87563-TR1G Real Image MGA-87563-TR1G Real Image1 MGA-87563-TR1G Real Image2
Same model may have multiple batches, images only for reference.

MGA-87563-TR1G

Part No MGA-87563-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP MMIC GAAS LNA 3/5V SOT363
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 500MHz to 4GHz
P1dB -2dBm (0.6mW)
Gain 11dB to 14dB
Noise Figure 1.6dB
RF Type Cellular, GPS, ISM, PCS
Supply Voltage - Operating 3V, 5V
Operating Supply Current 4.5mA
Test Frequency 2GHz
Case / Package SOT-363, SC70
Win Source Part Number 023220-MGA-87563-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MGA-87563
Introduction Date April 01, 2004
ECCN 5A991.g
Country of Origin Malaysia
Estimated EOL Date Obsolete
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-87563-TR1G CAD Model

Description

The Broadcom Limited MGA-87563 is a RF amplifier designed for cellular, GPS, ISM, and PCS RF types.

  • Frequency Range: 500MHz to 4GHz
  • Gain: 11dB to 14dB
  • Noise Figure: 1.6dB
  • P1dB: -2dBm (0.6mW)
  • Test Frequency: 2GHz
  • Operating Supply Voltage: 3V or 5V
  • Supply Current: 4.5mA
  • Case/Package: SOT-363 and SC70
  • Packaging: Reel-TR
  • RF Type: Cellular, GPS, ISM, PCS
  • Manufacturer: Broadcom Limited
  • Popularity: High
