MGA-71543-TR1G Broadcom Limited MGA-71543-TR1G label picture MGA-71543-TR1G real image MGA-71543-TR1G real image 2
Same model may have multiple batches, images only for reference.
MGA-71543-TR1G Broadcom Limited MGA-71543-TR1G label picture MGA-71543-TR1G real image MGA-71543-TR1G real image 2
MGA-71543-TR1G Broadcom Limited MGA-71543-TR1G label picture MGA-71543-TR1G real image MGA-71543-TR1G real image 2
Same model may have multiple batches, images only for reference.

MGA-71543-TR1G

Part No MGA-71543-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP MMIC LNA GAAS 3V SOT343
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 100MHz to 6GHz
P1dB 13.1dBm (20.4mW)
Gain 15.4dB
Noise Figure 0.8dB
RF Type CDMA, TDMA, PCS
Supply Voltage - Operating 2.7 V to 4.2 V
Operating Supply Current 50mA
Test Frequency 2.01GHz
Case / Package SOT-343, SC70 4-Lead
Win Source Part Number 058488-MGA-71543-TR1G
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-71543-TR1G CAD Model

Description

The Broadcom Limited 058488-MGA-71543-TR1G is an active RF amplifier that operates in the frequency range of 100MHz to 6GHz.

  • Frequency Range: 100MHz to 6GHz
  • Gain: 15.4dB
  • Noise Figure: 0.8dB
  • P1dB: 13.1dBm
  • Suitable for: CDMA, TDMA, and PCS applications
  • Package: SOT-343, SC70 4-Lead package
  • Operating Voltage: 2.7V to 4.2V
  • Operating Supply Current: 50mA
  • Popularity: Medium popularity
  • Supply and Demand Status: Balanced
