HCPL-7800-500E

Name: HCPL-7800-500E
Brand: Broadcom Limited
SKU: 142088
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	HCPL-7800-500E
Manufacturer	Broadcom Limited
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP ISOLATION 100KHZ 8DIPGW
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Amplifier Type	Isolation
Number of Circuits	1
-3db Bandwidth	100kHz
Current - Input Bias	500nA
Voltage - Input Offset	300μV
Operating Supply Current	10.9mA
Channel Output Current	16mA
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-DIP Gull Wing
Win Source Part Number	086998-HCPL-7800-500E
Family Name	HCPL-7800
Introduction Date	October 27, 2004
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Not Compliant
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	1k pcs
Ultra Librarian 3D Model	Ultra Librarian HCPL-7800-500E CAD Model

Description

The Broadcom Limited HCPL-7800-500E is an isolation amplifier in the integrated circuits category. Supply and demand is balanced.

Package: 8-DIP Gull Wing
Operating Supply Voltage: 4.5V to 5.5V
Bandwidth: 100kHz
Channel Output Current: 16mA
Operating Supply Current: 10.9mA
Ideal for: Applications requiring high gain, low noise, and high isolation.
