HCPL-2631-300E Real Image HCPL-2631-300E real image21600
Same model may have multiple batches, images only for reference.
HCPL-2631-300E Real Image HCPL-2631-300E real image21600
HCPL-2631-300E Real Image HCPL-2631-300E real image21600
Same model may have multiple batches, images only for reference.

HCPL-2631-300E

Part No HCPL-2631-300E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL 8DIP GW / Optocoupler Logic-Out Open Collector Dc-In 2-Ch 8-Pin Pdip Smd Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Minimum) 10kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Output Current per Channel 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Maximum) 100ns, 100ns
Rise / Fall Time (Typ) 24ns, 10ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Maximum) 15mA
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 8-SMD, Gull Wing
Manufacturer Package 8-DIP Gull Wing
Win Source Part Number 775709-HCPL-2631-300E
Popularity Medium
Supply and Demand Status Limited
Quantity per package 50
Family Name HCPL-2631
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-2631-300E CAD Model

Description

The Broadcom Limited HCPL-2631-300E is a medium popularity device designed for use in Isolators.

  • Operating Temperature Range: -40°C to 85°C
  • Packaging: Tube
  • Voltage Isolation: 3750Vrms
  • Data Rate: 10MBd
  • Output Type: Open Collector, Schottky clamped
  • Input Type: DC
  • Voltage Forward (Vf): 1.5V
  • Rise/Fall Time (Typ): 24ns, 10ns
  • Output Current Per Channel: 50mA
  • DC Forward Current (If) (Maximum): 15mA
  • Common Mode Transient Immunity (Minimum): 10kV/μs
  • Propagation Delay tpLH / tpHL (Maximum): 100ns, 100ns
  • Quantity per Package: 50

in the open market.

The supply and demand status of the device is limited, and it has a quantity per package of 50.
