HCPL-2430 Real Image HCPL-2430 Real Image
Same model may have multiple batches, images only for reference.
HCPL-2430 Real Image HCPL-2430 Real Image
HCPL-2430 Real Image HCPL-2430 Real Image
Same model may have multiple batches, images only for reference.

HCPL-2430

Part No HCPL-2430
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 40MBd
Propagation Delay tpLH / tpHL (Max) 55ns, 55ns
Rise and Fall Time 20ns, 10ns
Forward Voltage 1.3V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 067892-HCPL-2430
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Power Management, Communications & Networking, Signal Processing
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-2430 CAD Model

Description

The Broadcom Limited Isolator is a high-quality isolator designed to provide reliable and efficient performance.

  • Channels: 2
  • Applications: Computers and Computer Peripherals, Power Management, Communications and Networking, and Signal Processing
  • Data Rate: 40MBd
  • Isolation Voltage: 3750Vrms
  • Mounting: SMD (SMT)
  • Operating Temperature: -40°C to 85°C
