HCPL-2232 Real Image HCPL-2232 Real Image1 HCPL-2232 Real Image2
Same model may have multiple batches, images only for reference.
HCPL-2232 Real Image HCPL-2232 Real Image1 HCPL-2232 Real Image2
HCPL-2232 Real Image HCPL-2232 Real Image1 HCPL-2232 Real Image2
Same model may have multiple batches, images only for reference.

HCPL-2232

Part No HCPL-2232
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 300ns, 300ns
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 067889-HCPL-2232
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Sensing & Instrumentation, Power Management
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-2232 CAD Model

Description

The Broadcom Limited HCPL-2232 is a high-speed optocoupler with a push-pull, totem pole output.

  • Output Type: Push-Pull, Totem Pole
  • Data Rate: 5MBd
  • Forward Voltage: 1.5V
  • Operating Temperature: -40°C to 85°C
  • Input Type: DC
  • Channel(s): 2
  • Inputs (Side 1/Side 2): 2/0
  • Common Mode Transient Immunity: 10kV/μs
  • Propagation Delay: 300ns (tpLH/tpHL max)
  • Package: 8-DIP gull wing
  • Pieces per Package: 50
