HCPL-090J-500E

Name: HCPL-090J-500E
Brand: Broadcom Limited
SKU: 596354
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-090J-500E
Manufacturer	Broadcom Limited
Catalog	Digital Isolators
Description	High Speed Digital Isolators \| DGTL ISO 2.5KV GEN PURP 16SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel
Technology	GMR (Giant Magnetoresistive)
Type	Use For General
Isolated Power	No
Number of Channels	4
Inputs - Side 1/Side 2	4/0
Channel Type	Unidirectional
Voltage - Isolation	2500Vrms
Common Mode Transient Immunity (Minimum)	15kV/μs
Data Rate	110MBd
Propagation Delay tpLH / tpHL (Maximum)	15ns, 15ns
Pulse Width Distortion (Maximum)	3ns
Rise / Fall Time	1ns, 1ns
Supply Voltage (V)	3V ~ 5.5V
Temperature Range - Operating	-55°C ~ 125°C
Mounting Style	SMD
Manufacturer Package	16-SOIC
Supplier Device Package	16-SOIC
Manufacturer Pack Quantity	1
MSL Level	1 (Unlimited)
Win Source Part Number	1179042-HCPL-090J-500E
Manufacturer Homepage	www.avagotech.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian HCPL-090J-500E CAD Model

Description

The Broadcom Limited electronic component is a GMR technology isolator with a data rate of 110MBd. It has a high voltage-isolation of 2500Vrms and a pulse width distortion of 3ns.

Win Source Part Number: 1179042-HCPL-090J-500E
Packaging: reel
Supply and demand status: limited
Description: It is suitable for use in various applications and is known for its high performance and reliability.
