HCPL-063L-000E Real Image HCPL-063L-000E real image
Same model may have multiple batches, images only for reference.
HCPL-063L-000E Real Image HCPL-063L-000E real image
HCPL-063L-000E Real Image HCPL-063L-000E real image
Same model may have multiple batches, images only for reference.

HCPL-063L-000E

Part No HCPL-063L-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description High Speed LVTTL Compatible 3.3 Volt Optocouplers | OPTOISO 3.75KV 2CH OPEN COLL 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Minimum) 10kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Current - Output / Channel 50mA
Data Rate 15MBd
Propagation Delay tpLH / tpHL (Maximum) 75ns, 75ns
Rise / Fall Time 24ns, 10ns
Voltage - Forward (Vf) 1.5V
Current - DC Forward (If) (Maximum) 15mA
Supply Voltage (V) 2.7V ~ 3.6V, 4.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO Tall
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1179028-HCPL-063L-000E
Manufacturer Homepage www.avagotech.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HCPL-063L-000E CAD Model

Description

The Broadcom Limited HCPL-063L-000E is a 2-channel optocoupler that has an open collector and Schottky clamped output type.

  • Channels: 2
  • Output Type: open collector and Schottky clamped
  • Data Rate: 15MBd
  • Input Type: DC
  • Current Output: 50mA per channel
  • Voltage Isolation: 3750Vrms
  • Package: 8-SO Tall
  • Mounting Style: SMD
  • Popularity: high
  • Supply and Demand Status: limited
  • Common Mode Transient Immunity: 10kV/μs
  • Propagation Delay: 75ns tpLH and tpHL maximum
