HCNW2611-000E Real Image HCNW2611-000E Real Image1 HCNW2611-000E Real Image2
Same model may have multiple batches, images only for reference.
HCNW2611-000E Real Image HCNW2611-000E Real Image1 HCNW2611-000E Real Image2
HCNW2611-000E Real Image HCNW2611-000E Real Image1 HCNW2611-000E Real Image2
Same model may have multiple batches, images only for reference.

HCNW2611-000E

Part No HCNW2611-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV OPEN COLLECTOR 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.64V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 126164-HCNW2611-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name HCNW2611
Introduction Date November 01, 2003
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 42
Ultra Librarian 3D Model Ultra Librarian HCNW2611-000E CAD Model

Description

The Broadcom Limited HCNW2611-000E is a high-popularity electronic component.

  • Case/Package: 8-DIP
  • Operating Supply Voltage: 4.5V to 5.5V
  • Data Rate: 10MBd
  • Common Mode Transient Immunity: 15kV/μs
  • Isolation Voltage: 5000Vrms
  • Input Type: DC
  • Number of Channels: 1
  • Win Source Part Number: 126164-HCNW2611-000E
  • Alternative Parts: PC910L0YSZ0F, PC910L0NSZ0F, 6N137
