ACPL-214-500E Real Image ACPL-214-500E Real Image1 ACPL-214-500E Real Image2 ACPL-214-500E Real Image3 ACPL-214-500E Real Image4 ACPL-214-500E Real Image5
Same model may have multiple batches, images only for reference.
ACPL-214-500E Real Image ACPL-214-500E Real Image1 ACPL-214-500E Real Image2 ACPL-214-500E Real Image3 ACPL-214-500E Real Image4 ACPL-214-500E Real Image5
ACPL-214-500E Real Image ACPL-214-500E Real Image1 ACPL-214-500E Real Image2 ACPL-214-500E Real Image3 ACPL-214-500E Real Image4 ACPL-214-500E Real Image5
Same model may have multiple batches, images only for reference.

ACPL-214-500E

Part No ACPL-214-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3KV TRANS 4SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3000Vrms
Minimum DC Current Transfer Ratio 20% @ 1mA
Maximum DC Current Transfer Ratio 400% @ 1mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 4-SO
Win Source Part Number 007868-ACPL-214-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Test & Measurement, Industrial
Family Name ACPL-214
Introduction Date April 17, 2007
ECCN EAR99
Country of Origin China, Singapore
Halogen Free Compliant
Estimated EOL Date 2023
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ACPL-214-500E CAD Model

Description

ACPL-214-500E Dual-Channel Optocoupler

The ACPL-214-500E is designed for high efficiency in signal transfer applications, featuring a dual-channel format that allows for multiple signal isolations in a single package.

  • Features and Benefits:
    • Dual-channel design maximizes space efficiency.
    • Wide operating temperature range for versatile application use.
    • High gain stability over temperature and supply voltage changes.
  • Applications/Projects:
    • Telecommunications equipment
    • Multiple data line isolation
    • Industrial control systems
    • Consumer electronics

Additional Details: The ACPL-214-500E supports a range of industrial protocols, making it a flexible solution for diverse application requirements.
