SRU1028A-820Y

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRU1028A-820Y
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRU1028A-820Y Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRU1028A
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	82 µH
Tolerance	±30%
Current Rating (Amps)	900 mA
Current - Saturation (Isat)	850mA
Shielding	Shielded
DC Resistance (DCR)	420mOhm Max
Q @ Freq	20 @ 2.52MHz
Frequency - Self Resonant	8MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)	0.122" (3.10mm)
Base Product Number	SRU1028A
Other Names	SRU1028A-820YTR,SRU1028A-820YCT,SRU1028A-820YDKR,SRU1028A-820Y
Standard Package	1,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273153-SRU1028A-820Y
Ultra Librarian 3D Model	Ultra Librarian SRU1028A-820Y CAD Model

Alternative Products

Description

The Bourns Inc. SRU1028A-820Y is a fixed inductor with an inductance of 82 μH and a tolerance of ±30%.

Inductance: 82 μH
Tolerance: ±30%
DC Resistance (DCR): 420mOhm Max
Current Rating: 900 mA
Shielding: Yes
Q @ Freq: 20 @ 2.52MHz
Frequency Self-Resonant: 8MHz
Height: 0.122 inches (3.10mm)
Mounting Type: SMD (SMT)
Applications: Inductors, coils, and chokes
Temperature Range: -40°C to 125°C
