SRR1260A-151K

Part No SRR1260A-151K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR1260A-151K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR1260A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 150 µH
Tolerance ±10%
Current Rating (Amps) 1.55 A
Current - Saturation (Isat) 1.55A
Shielding Shielded
DC Resistance (DCR) 260mOhm Max
Q @ Freq 20 @ 796kHz
Frequency - Self Resonant 5MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.256" (6.50mm)
Base Product Number SRR1260A
Other Names SRR1260A-151KDKR,SRR1260A-151KCT,SRR1260A-151K,SRR1260A-151KTR
Standard Package 600
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273425-SRR1260A-151K
Ultra Librarian 3D Model Ultra Librarian SRR1260A-151K CAD Model

Description

The Bourns Inc. 1273425-SRR1260A-151K is a fixed inductor that is ideal for use in a range of applications.

  • Core: shielded drum
  • Wirewound Type: wirewound
  • Core Material: ferrite
  • Inductance: 150µH
  • Tolerance: ±10%
  • Q: 20 @ 796kHz
  • Rated: AEC-Q200
