Same model may have multiple batches, images only for reference.
SRP4020-5R6M Real Image
Same model may have multiple batches, images only for reference.

SRP4020-5R6M

Part No SRP4020-5R6M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP4020
Package Tape & Reel (TR)
Product Status Obsolete
Type Molded
Material - Core Iron
Inductance 5.6 µH
Tolerance ±20%
Current Rating (Amps) 2.4 A
Current - Saturation (Isat) 3.5A
Shielding Shielded
DC Resistance (DCR) 90mOhm Max
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.189" L x 0.157" W (4.80mm x 4.00mm)
Height - Seated (Max) 0.079" (2.00mm)
Base Product Number SRP4020
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273922-SRP4020-5R6M
Ultra Librarian 3D Model Ultra Librarian SRP4020-5R6M CAD Model

Description

The Bourns Inc. 1273922-SRP4020-5R6M is a fixed inductor component from the SRP4020 series.

  • Type: Molded and shielded
  • Inductance: 5.6 µH
  • Mounting: SMD (SMT)
  • Height-Seated (Max): 0.079" (2.00mm)
  • Standard Package: 2,000
  • Tolerance: ±20%
  • Material Core: iron
  • DC Resistance (DCR): 90mOhm Max
  • Operating Temperature: -55°C to 125°C
  • Dimension: 0.189" L x 0.157" W (4.80mm x 4.00mm)
  • Current Rating (Amps): 2.4 A
  • Inductance Frequency-Test: 100 kHz
