SM8SF24A-Q

Name: SM8SF24A-Q
Brand: Bourns Inc.
SKU: 1301561
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SM8SF24A-Q
Manufacturer	Bourns Inc.
Catalog	TVS - Diodes
Datasheet	SM8SF24A-Q Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection>TVS - Diodes
Mfr	Bourns Inc.
Series	Automotive, AEC-Q101, SM8SF-Q
Package	Tape & Reel
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	24V
Voltage - Breakdown (Min)	26.7V
Voltage - Clamping (Max) @ Ipp	38.9V
Current - Peak Pulse (10/1000µs)	180A
Power - Peak Pulse	7000W (7kW)
Power Line Protection	No
Applications	Automotive
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting	SMD (SMT)
Package / Case	2-LDFN
Supplier Device Package	2-DFN (8.1x10.5)
Base Product Number	SM8SF
Other Names	SM8SF24A-QCT,SM8SF24A-QTR,SM8SF24A-QDKR
Standard Package	750
MSL Level	1 (Unlimited)
REACH Status	REACH Affected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	1301561-SM8SF24A-Q
Ultra Librarian 3D Model	Ultra Librarian SM8SF24A-Q CAD Model

Alternative Products

Description

The Bourns Inc. 1301561-SM8SF24A-Q is a Zener type TVS diode that is designed for circuit protection in automotive applications.

Manufacturer: Bourns Inc.
Type: Zener
Application: Circuit protection in automotive applications
Voltage Reverse Standoff: 24V
Breakdown Voltage: 26.7V
Maximum Voltage Clamping @ Ipp: 38.9V
Peak Pulse Power: 7,000W (7kW)
Peak Pulse Current: 180A
Package: 2-LDFN
Operating Temperature: -55°C to 175°C (TJ)
Channel: Unidirectional
Channels: One
Packaging: Tape and reel
Standard Package: 750
Capacitance @ Frequency: Not specified
REACH: REACH affected
ECCN: EAR99
