SDE1006A-270M Real Image
Same model may have multiple batches, images only for reference.

SDE1006A-270M

Part No SDE1006A-270M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE1006A-270M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE1006A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 27 µH
Tolerance ±20%
Current Rating (Amps) 2.3 A
Current - Saturation (Isat) 2.5A
Shielding Unshielded
DC Resistance (DCR) 110mOhm Max
Frequency - Self Resonant 13.3MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) 0.228" (5.80mm)
Base Product Number SDE1006A
Other Names SDE1006A-270M,SDE1006A-270MCT,SDE1006A-270MDKR,SDE1006A-270MTR
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274879-SDE1006A-270M
Ultra Librarian 3D Model Ultra Librarian SDE1006A-270M CAD Model

Description

The Bourns Inc. SDE1006A fixed inductor is a drum core, wirewound inductor with an inductance of 27 µH.

  • Mounting: SMD (SMT)
  • Rating: AEC-Q200
  • Core Material: Ferrite
  • Tolerance: ±20%
  • Packaging: Nonstandard
  • Height: 0.228" (5.80mm)
  • Package Quantity: 800 pieces
