The 4308R-101-121LF is a thick film isolated resistor network from Bourns Inc. These resistor networks are designed to provide multiple resistors in a single package, saving space and simplifying circuit design. The 'LF' suffix indicates that the component is lead-free, complying with RoHS standards.

Applications

• Current limiting
• Voltage division
• Pull-up/pull-down resistors in digital circuits
• Input protection for operational amplifiers
• Logic circuit termination

Features

• Isolated resistor configuration
• Thick film technology
• Compact 8-pin package
• Lead-free construction (RoHS compliant)
• Stable resistance values over temperature

Benefits

• Saves board space compared to discrete resistors
• Simplifies circuit layout
• Improves reliability by reducing the number of solder joints
• Reduces component count
• Meets environmental regulations

Additional Details

The 4308R-101-121LF has a resistance value of 120 ohms. The '101' marking is a standard EIA code where the first two digits represent the significant figures, and the third digit represents the number of zeros. It has an isolated configuration where each resistor is electrically isolated from the others. It features a power rating (typically around 0.125W per resistor or 0.75W total package), and is designed for reflow soldering processes. The resistance tolerance is typically ±2% or ±5%, depending on the specific datasheet. The temperature coefficient of resistance (TCR) is typically ±100 ppm/°C.
