3590S-2-101L Real Image 3590S-2-101L real image 3590S-2-101L real image 2
Same model may have multiple batches, images only for reference.
3590S-2-101L Real Image 3590S-2-101L real image 3590S-2-101L real image 2
3590S-2-101L Real Image 3590S-2-101L real image 3590S-2-101L real image 2
Same model may have multiple batches, images only for reference.

3590S-2-101L

Part No 3590S-2-101L
Manufacturer Bourns Inc.
Catalog Rotary Potentiometers, Rheostats
Description POT 100 OHM 2W WIREWOUND LINEAR
Datasheet
3590S-2-101L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Potentiometers, Variable Resistors
Manufacturer Bourns Inc.
Packaging Bulk
Status Active
Taper Linear
Resistance (Ohms) 100
Tolerance ±5%
Number of Gangs 1
Built in Switch None
Power (Watts) 2W
Temperature Coefficient ±50ppm/°C
Number of Turns 10
Rotation 3600°
Adjustment Type User Defined
Resistive Material Wirewound
Termination Style Solder Lug
Actuator Type Slotted
Actuator Length 0.812" (20.63mm)
Actuator Diameter 0.2497" (6.34mm)
Bushing Thread 3/8-32
Mounting Panel Mount
Win Source Part Number 1005206-3590S-2-101L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name 3590
Introduction Date October 15, 1997
ECCN EAR99
Country of Origin India, Mexico
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian 3590S-2-101L CAD Model

Description

The Bourns Inc. 1005206-3590S-2-101L is a high-quality potentiometer that is widely used in various applications.

  • Tolerance: ±5%
  • Temperature Coefficient: ±50ppm/°C
  • Power Rating: 2W
  • Resistance: 100 ohms
  • Actuator Type: Slotted
  • Actuator Length: 0.812" (20.63mm)
  • Actuator Diameter: 0.2497" (6.34mm)
  • Mounting Type: Panel Mount
  • Bushing Thread: 3/8-32
  • Type: User Defined
  • Taper: Linear
  • Turns: 10
  • Status: Active
  • Popularity: High
  • Supply and Demand: Limited
