DP4320-9RDG Real Image
Same model may have multiple batches, images only for reference.

DP4320-9RDG

Part No DP4320-9RDG
Manufacturer Bel Power Solutions
Catalog Power Supplies Board Mount DCDC Converters
Description DC/DC CONVERTER 4X12V 384W / Enclosed, Conformal Coated DC DC Converter 4 Output 12V 12V 12V 12V 8A, 8A, 8A, 8A 90V Input
Datasheet
DP4320-9RDG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board)>DC DC Converters
Mfr Bel Power Solutions
Series Melcher P (90 ~ 192W)
Package Bulk
Type Enclosed, Conformal Coated
Voltage - Input (Min) 40V
Voltage - Input (Max) 90V
Number of Outputs 4
Voltage - Output 1 12V
Voltage - Output 2 12V
Voltage - Output 3 12V
Voltage - Output 4 12V
Current - Output (Max) 8A, 8A, 8A, 8A
Power (Watts) 384W
Voltage - Isolation 4.2 kV
Applications ITE (Commercial), Railway
Efficiency 88%
Temperature Range - Operating -40°C ~ 71°C
Mounting Type Chassis Mount
Dimension 6.46" L x 4.37" W x 0.78" H (164.0mm x 111.0mm x 19.8mm)
Approval Agency cCSAus, CE, NEMKO
Base Product Number DP4320
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Standard Package 10
Win Source Part Number 1055878-DP4320-9RDG
Ultra Librarian 3D Model Ultra Librarian DP4320-9RDG CAD Model

Description

The Bel Power Solutions Melcher P series DC-DC converters are designed for use in ITE (Commercial) and railway applications.

  • Power Rating: 384W
  • Voltage Isolation: 4.2 kV
  • Outputs: four outputs
  • Current Output: 8A each
  • Voltage Input Range: 40V to 90V
  • Efficiency: 88%
  • Operating Temperature Range: -40°C to 71°C
  • Package: enclosed, conformal coated
  • Mounting: chassis mounted
  • Ideal for: applications such as railway systems, power distribution, and telecommunications
