The SR217A151JARTR1 is a multilayer ceramic capacitor (MLCC) manufactured by AVX Corp/Kyocera Corp. It is designed for surface mount applications and offers a combination of high capacitance and high voltage rating in a compact package, making it suitable for various electronic applications where space and performance are critical.

Applications

• High voltage power supplies
• Snubber circuits
• DC-DC converters
• High frequency inverters
• Voltage multipliers

Features

• Capacitance: 150pF
• Voltage Rating: 1000V (1kV)
• Dielectric Material: C0G (NP0)
• Case Size: 2220 (EIA)
• Termination: Surface Mount (SMD)
• RoHS Compliant

Benefits

• Extremely stable capacitance with minimal change over temperature and voltage (C0G/NP0 dielectric)
• High voltage operation suitable for demanding applications
• Compact size for space-constrained designs
• Easy to integrate using surface mount technology
• Reliable performance in high-stress environments
• Environmentally friendly due to RoHS compliance

Additional Details

The SR217A151JARTR1 utilizes a C0G (NP0) dielectric material. This dielectric is known for its exceptional stability, exhibiting virtually no change in capacitance with variations in temperature, voltage, or frequency. The temperature coefficient is typically ±30 ppm/°C, ensuring consistent performance across a wide operating temperature range. The 2220 case size provides a balance between capacitance and size, allowing for high-density board layouts. This MLCC is well-suited for high-frequency applications due to its low equivalent series resistance (ESR) and equivalent series inductance (ESL). It is commonly used in applications requiring precision timing and filtering. The tape and reel packaging allows for automated pick-and-place assembly, contributing to efficient manufacturing processes. Its high insulation resistance contributes to its reliability in high-voltage circuits.
