NSF03A20 Nihon Inter Electronics Corporation
Same model may have multiple batches, images only for reference.

NSF03A20

Part No NSF03A20
Manufacturer AVX Corp/Kyocera Corp
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 200V 3A NSMC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr AVX Corp/Kyocera Corp
Package Tape & Reel
Product Status Obsolete
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 980 mV @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 30 ns
Current - Reverse Leakage @ Vr 10 µA @ 200 V
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package nSMC
Operating Temperature - Junction -40°C ~ 150°C
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 259826-NSF03A20
Ultra Librarian 3D Model Ultra Librarian NSF03A20 CAD Model

Description

The 259826-NSF03A20 is a fast recovery diode rectifier designed for use in discrete semiconductor products.

  • Manufacturer: Manufactured by AVX Corp/Kyocera Corp, this diode has a voltage rating of 200 V and an average rectified current of 3A.
  • Recovery time: It has a fast recovery time of 30 ns
  • Reverse leakage current: a reverse leakage current of 10 µA @ 200 V.
  • Package: The diode comes in a tape and reel package, with a standard package containing 3,000 pieces.
  • ECCN classification: It has an ECCN classification of EAR99
  • HTSUS code: an HTSUS code of 8541.10.0080.
  • Status: The 259826-NSF03A20 is an obsolete product, meaning it is no longer in production.
