209257016001013 AVX Corp/Kyocera Corp – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

209257016001013

Part No 209257016001013
Manufacturer AVX Corp/Kyocera Corp
Catalog Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 16P 0.049 GOLD SMD R/A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Receptacle
Contact Type Female Blade Socket
Style Board to Cable/Wire
Number of Positions 16
Number of Positions Loaded All
Pitch - Mating 0.049" (1.25mm)
Number of Rows 2
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Friction Lock
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 31.5µin (0.80µm)
Insulation Height 0.118" (3.00mm)
Temperature Range - Operating -55°C ~ 85°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Features Board Guide, Shielded, Solder Retention
Current Rating (Amps) 1A per Contact
Voltage Rating 125VAC
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1628772-209257016001013
Ultra Librarian 3D Model Ultra Librarian 209257016001013 CAD Model
